Aube Thermostats are a leading brand‚ renowned for innovative‚ user-friendly electronic thermostats. Now part of Honeywell Home and Resideo‚ Aube focuses on high-quality products‚ easy to install and operate‚ with comprehensive user information.
Brand Overview and Vision
Aube Technologies stands as a leading brand in electronic heating controls‚ recognized for its innovative and user-friendly products. Specializing in thermostats‚ relays‚ and timers for diverse electric heating systems‚ Aube’s vision prioritizes high-quality‚ technologically advanced‚ yet straightforward devices. Their products are designed to be exceptionally easy to install and operate effectively‚ ensuring optimal comfort‚ precise temperature management‚ and enhanced energy efficiency for both residential and commercial environments‚ thereby meeting practical user needs for superior climate control.
Now operating as a distinguished product line under Honeywell Home and Resideo‚ Aube skillfully leverages broader corporate resources while meticulously preserving its specialized expertise in advanced heating solutions. This strategic integration significantly solidifies its market standing‚ empowering Aube to consistently deliver reliable and intuitive climate control options that meet modern demands. The brand passionately upholds its core ethos of engineering excellence and unwavering customer satisfaction within the rapidly evolving intelligent home sector. This alignment supports Aube’s objective to expand its market reach‚ focusing on simplifying heating management and promoting sustainable energy efficiency through forward-thinking technological approaches.
Product Range and User Manuals
Aube offers an extensive product range for various heating and cooling applications‚ including programmable and non-programmable thermostats. Key models include the TH115 series for programmable electric heating‚ the TH114 non-programmable thermostat for ambient or floor temperature control‚ and the TH136 with advanced Proportional Integral Adaptive (PIA) technology. Further options include the TH146 series for diverse HVAC systems and connectable devices‚ and the TH150 series for Variable Air Volume (VAV) applications. The product line also features essential accessories‚ such as the AC146-410 temperature sensor‚ enhancing precise environmental management.
To support users‚ Aube provides comprehensive user manuals for its entire product line. These crucial guides‚ comprising 49 manuals for 39 models‚ are indispensable for proper installation‚ configuration‚ and daily operation. They offer detailed instructions on setup‚ including clock and day settings‚ temperature scale (C/F) and time format selection‚ and understanding various system operating modes. All PDF user guides are conveniently available online for download or viewing‚ ensuring users have immediate access to information needed to fully utilize their Aube thermostat’s capabilities for optimal comfort and energy efficiency.
Aube as Honeywell Home and Resideo Product Line
Aube Technologies‚ long recognized for its expertise in electronic thermostats‚ relays‚ and timers tailored for electric heating systems‚ now operates as a specialized product line under the esteemed Honeywell Home and Resideo brands. This evolution underscores Aube’s continued commitment to innovation‚ bolstered by the extensive resources and global reach of its parent companies. By integrating into Honeywell Home and Resideo‚ Aube enhances its capacity for research and development‚ ensuring its advanced climate control solutions remain cutting-edge and align with broader smart home ecosystems. This strategic alignment provides consumers with the assurance of robust engineering‚ superior product reliability‚ and comprehensive customer support‚ hallmarks of the Honeywell Home and Resideo legacy. Aube’s dedicated focus on precise temperature management for systems like baseboard heaters and radiant flooring perfectly complements the diverse offerings of its parent organization. This collaboration ensures that Aube’s specialized contributions continue to meet stringent performance standards‚ providing efficient and intuitive control options while benefiting from a wider distribution network and enhanced market visibility within the residential and commercial sectors.
General Installation Guidelines
For Aube thermostat installation‚ always deactivate power at the main panel to prevent electric shocks. Professional installation by a qualified technician is recommended. Carefully select a location‚ typically 5 feet above the floor‚ ensuring good air circulation for optimal performance.
Safety Precautions for Installation
Prioritizing safety during Aube thermostat installation is paramount. Always begin by deactivating the power to the heating system at the main electrical panel. This crucial step prevents electrical shock and ensures a safe working environment. It is strongly advised that installation be performed by a certified electrician or a qualified technician who understands national and local electrical codes. Carefully read all instructions provided in the user manual before disconnecting any existing wiring or attempting to connect the new thermostat. Aube thermostats are designed for specific load types; ensure your system is compatible. For instance‚ many Aube models are intended for resistive loads‚ such as electric baseboard heaters‚ radiant ceilings‚ and floors. Verify that your specific model’s load requirements‚ often detailed as resistive loads not exceeding certain amperage or wattage (e.g.‚ 4000W/240Vac or 2000W/120Vac)‚ are met. Avoid using these thermostats with inductive loads‚ fan-forced heating systems‚ or central heating systems unless explicitly stated in your model’s manual. Additionally‚ be aware of minimum and maximum resistive load capacities‚ as installing outside these ranges can pose risks. Never install the thermostat in areas prone to excessive drafts or direct sunlight‚ which can compromise accurate temperature readings and system efficiency. Adhering to these precautions will ensure a safe and successful installation of your Aube thermostat.
Choosing Thermostat Location
Choosing the right location for your Aube thermostat is crucial for accurate temperature sensing and efficient system operation. For new installations‚ position it approximately 5 feet (1.5 meters) above the floor. This height allows the device to effectively read the average ambient air temperature. Good air circulation at the spot is essential for precision‚ ensuring it reflects overall thermal conditions accurately.
To maintain measurement integrity‚ avoid areas prone to skewed readings. This includes steering clear of direct sunlight‚ which can cause the thermostat to register falsely high temperatures. Similarly‚ do not place it near heat-emitting sources like appliances‚ lamps‚ fireplaces‚ or hot air vents. Drafts from windows‚ doors‚ or external walls are detrimental‚ leading to erratic temperature control and wasteful heating cycles. An interior wall is generally the best choice‚ ensuring the thermostat accurately reflects the average temperature of its controlled zone for consistent comfort and optimal energy savings.
Professional Installation Recommendation
For the installation of Aube thermostats‚ it is strongly recommended that the task be performed by a certified electrician or a qualified technician. This recommendation stems from several critical factors‚ primarily ensuring safety and compliance with electrical standards. As highlighted in various Aube user manuals‚ such as those for the TH115 series or TH144‚ installation procedures often involve working with electrical wiring and main power panels. Turning off power to the system at the main power panel is a vital safety precaution to prevent electrical shock‚ a step best handled by someone with expertise.
Moreover‚ installations must strictly comply with all national and local electrical codes. A professional installer possesses the necessary knowledge to ensure your Aube thermostat is installed correctly and legally‚ avoiding potential hazards or future issues. Incorrect wiring or improper setup can not only pose safety risks but also lead to inefficient operation or damage to the thermostat and heating system. While user manuals provide detailed instructions‚ the complexity of certain systems‚ or simply the desire for peace of mind‚ makes professional expertise invaluable for optimal performance and reliable control of your heating system.
Wiring Guidelines
Proper wiring is fundamental for the safe and efficient operation of Aube thermostats. These devices are primarily designed to control electric heating systems such as baseboard heaters‚ radiant floors and ceilings‚ and convectors. It is crucial to understand compatibility before commencing any wiring. Aube thermostats are generally suitable for resistive loads‚ often specifying precise limits. For instance‚ some models are designed for resistive loads not exceeding 4000W at 240Vac or 2000W at 120Vac‚ and typically have defined minimum and maximum amperage ratings‚ such as avoiding loads under 0.83 A or over 8.3 A for certain units. Crucially‚ Aube thermostats are explicitly incompatible with specific setups‚ including inductive loads‚ fan-forced heating systems‚ or central heating systems that utilize a low-voltage controller. Furthermore‚ certain models‚ like the TH132‚ specifically require installation only with a TRIAC relay for proper functionality. Always consult the specific model’s user manual for precise wiring diagrams‚ detailed load specifications‚ and comprehensive system compatibility information‚ including guidelines for connecting external sensors or control modules where applicable‚ to ensure a correct and safe installation that adheres to all technical requirements.
Common Thermostat Features and Operation
Aube thermostats feature common operations: manual/automatic modes‚ system selections‚ and clock/day settings. Users adjust temperature scale (C/F) and time format (12/24hr). A heating intensity indicator offers clear feedback.
Manual and Automatic Modes
Aube thermostats provide versatile operation through both manual and automatic modes‚ designed to meet diverse user preferences and energy management strategies. In manual mode‚ users gain direct‚ immediate control over their heating or cooling system. This allows for precise‚ on-the-fly temperature adjustments‚ effectively overriding any programmed schedules. This functionality proves beneficial for short-term deviations from routine or in non-programmable thermostat models‚ such as the TH114‚ which primarily focuses on maintaining a constant desired temperature. Manual mode offers simplicity and direct user intervention for temporary climate control needs.
Conversely‚ the automatic mode fully leverages the thermostat’s advanced programmable capabilities for optimized comfort and efficiency. Here‚ the device meticulously follows a pre-set schedule‚ automatically adjusting temperature throughout the day and week. This feature is fundamental to programmable units like the TH115 series and TH136‚ enabling users to define comfort zones for daily periods‚ including “wake‚” “away‚” “home‚” and “sleep.” Automatic mode delivers consistent‚ hands-free climate regulation‚ significantly contributing to energy conservation by operating only when necessary. Users can seamlessly transition between these modes‚ achieving an optimal balance of convenience and environmental command.
System Operating Modes
Aube thermostats provide a comprehensive range of system operating modes‚ allowing users to precisely manage their indoor climate. These modes are typically accessible via a dedicated “Mode” button on the thermostat’s interface‚ catering to various heating and cooling needs. The fundamental modes include HEAT‚ COOL‚ and AUTO.
In HEAT mode‚ the system is configured solely for warming your environment. It activates the heating apparatus‚ such as a furnace or baseboard heaters‚ whenever the room temperature falls below the user-defined setpoint. Conversely‚ COOL mode engages the air conditioning system‚ working to reduce the temperature when it exceeds the setpoint‚ providing relief during warmer periods. Many Aube models also feature an OFF mode‚ which completely deactivates both heating and cooling functions‚ ideal for periods when climate control is not necessary or during system maintenance.
For optimal convenience and energy efficiency‚ the AUTO mode offers automatic changeover. In this intelligent setting‚ the thermostat dynamically switches between heating and cooling operations as required‚ maintaining your desired temperature range without manual intervention. Advanced models‚ like those in the TH146 series or TH149‚ can also support specific system types such as heat pumps and may offer additional options like Auxiliary Heat or dedicated fan modes‚ ensuring versatile and efficient climate control for diverse applications.
Clock and Day Setting Instructions
Setting the correct clock and day is critical for the accurate operation of Aube programmable thermostats‚ ensuring scheduled temperature changes occur precisely as desired. The process typically involves a clear sequence of steps‚ though specific button labels may vary slightly between models.
For many Aube thermostats‚ including the TH146 series‚ setting the time begins by pressing a dedicated “Clk” button. This action usually causes the hour display to flash‚ indicating it’s ready for adjustment. Users then employ the adjustment buttons‚ often represented by up/down arrows or plus/minus symbols‚ to navigate to the correct hour. A subsequent press of the “Clk” button will then make the minute display flash‚ allowing for precise minute adjustments using the same control keys.
To set the day‚ another press of the “Clk” button will prompt the day display to flash. Users can then cycle through the days of the week until the current day is selected. Once all adjustments are made‚ pressing “Clk” again or a designated “Exit” button will save the settings and return the thermostat to its normal display. Certain models‚ like the TH110A-DP-P or TH123‚ may feature individual “DAY‚” “HOUR‚” and “MIN” buttons for direct‚ intuitive adjustment. Always consult your specific Aube thermostat’s user manual for the most accurate and detailed instructions.
Temperature Scale (C/F) and Time Format (12/24hr) Selection
Aube thermostats offer flexibility in how temperature and time are displayed‚ catering to individual user preferences. Users can typically choose between Celsius (°C) and Fahrenheit (°F) for temperature readings‚ and a 12-hour or 24-hour format for the clock display.
The method for adjusting these settings varies by model. For some thermostats‚ such as the TH110A-DP-P‚ selection switches are conveniently located at the back of the unit. These switches allow for direct configuration of the temperature scale (C or F) and the time format (12 or 24 hours).
Other Aube models‚ like the TH101D and TH102D‚ utilize specific button combinations for these adjustments. To switch between Celsius and Fahrenheit‚ users often need to maintain the DAY button pressed down while simultaneously pressing and releasing the RESET button‚ then releasing the DAY button. Similarly‚ to toggle between 12-hour and 24-hour time formats‚ holding down the HOUR button as the RESET button is pressed and released is a common procedure. Always consult the specific user manual for your Aube thermostat model to accurately identify the correct configuration method for these important settings.
Heating Intensity Indicator
The Heating Intensity Indicator on Aube thermostats provides a useful visual cue regarding the heating system’s operation. When heating is off or not actively required‚ the display typically shows no specific indicator‚ signifying the ambient temperature is at or above the setpoint. This feature offers valuable insight into energy usage.
For example‚ on models like the Aube Technologies TH108PLUS‚ this indicator goes beyond a simple ‘on’ signal. Instead‚ it dynamically displays the percentage of heating time necessary to maintain the user’s desired temperature. If the display shows “40%”‚ it means the heating system is active for 40 percent of its cycle duration. This proportional representation offers a clear understanding of how intensively the system is working. It helps users gauge energy expenditure and thermostat efficiency in sustaining comfort. This dynamic insight allows for improved home energy awareness and more effective home climate management‚ promoting comfort and potential savings.
Aube Thermostat Models and Specific Applications
Aube offers a diverse portfolio of thermostats‚ each engineered for distinct heating and cooling applications. This section explores models like the programmable TH115‚ non-programmable TH114‚ TH136 with PIA‚ specialized TH150 for VAV‚ and the versatile AC146-410 sensor.
TH115 Series Programmable Thermostats
The Aube TH115 Series comprises sophisticated programmable thermostats‚ specifically engineered to optimize energy efficiency and elevate user comfort. Models within this series‚ such as the TH115 AF‚ TH115 A‚ and TH115 F‚ are primarily designed for precise control of electric heating systems‚ including baseboard heaters and radiant floors. Comprehensive user manuals are readily available‚ guiding users through every aspect of installation‚ programming‚ and daily operation. These guides detail the function of buttons‚ symbol interpretations‚ various operating modes‚ setpoint adjustments‚ schedule customization‚ and the utility of remote input features‚ ensuring a seamless user experience.
For safe and effective deployment‚ installation of any TH115 Series thermostat mandates execution by a certified electrician‚ in strict compliance with all national and local electrical codes. It is imperative to note that these thermostats are built exclusively for resistive loads and possess specific operational parameters: they are not suitable for resistive loads below 0.83 A or exceeding 8.3 A. Furthermore‚ the TH115 Series is incompatible with inductive loads‚ fan-forced heating systems‚ or central heating systems‚ underscoring their specialized application within dedicated electric heating setups.
TH114 Non-Programmable Thermostat
The Aube TH114 is a non-programmable thermostat specifically designed for straightforward and reliable temperature control. Its primary function is to efficiently manage either the ambient air temperature or the floor temperature‚ offering notable flexibility for diverse heating system setups. Users can easily select from distinct operational modes to precisely suit their specific requirements. In ‘A’ mode‚ the thermostat accurately controls and prominently displays the current ambient air temperature within the designated space. For applications specifically requiring floor heating management‚ the ‘F’ mode is optimally utilized‚ which meticulously controls and displays the floor temperature by integrating an essential external temperature sensor. Furthermore‚ the ‘AF’ mode provides a comprehensive and advanced solution by simultaneously controlling and displaying both the ambient air and floor temperatures‚ offering enhanced comfort and crucial protection against potential overheating. User manuals provide clear‚ concise instructions for setup and intuitive mode selection‚ ensuring effortless operation without complex programming schedules. This model is ideal for users seeking dependable‚ direct temperature regulation without the need for intricate scheduling features‚ proving itself a simple yet highly effective heating control solution.
TH136 Programmable Thermostat with PIA Technology
The Aube TH136 is a sophisticated programmable thermostat engineered for optimal temperature control and user comfort. Its defining feature is the integration of Proportional Integral Adaptive (PIA) temperature control technology. This advanced microprocessor-driven system continuously analyzes and adapts to the heating environment‚ ensuring exceptionally precise and stable temperature regulation. PIA technology significantly minimizes temperature fluctuations‚ providing a consistently comfortable living or productive working space. This adaptive capability also contributes substantially to energy efficiency by intelligently optimizing heating cycles and reducing unnecessary energy consumption effectively. Users benefit from the ability to set customized heating schedules‚ aligning perfectly with their daily routines for both convenience and tangible savings. The TH136 offers various operational modes‚ including manual and automatic settings‚ allowing for truly flexible control. Its user interface typically includes dedicated buttons for clock/day settings‚ program adjustments‚ and mode selection‚ all thoroughly detailed within the comprehensive user manual. Understanding its programmable features and innovative PIA technology is crucial for achieving optimal performance‚ maximizing comfort‚ and realizing substantial energy savings with this modern heating solution.
TH146 Series Applications and Connectable Devices
The Aube TH146 Series of electronic thermostats‚ including programmable (e.g.‚ TH146-P-2H1C) and non-programmable (e.g.‚ TH146-N-U) models‚ is engineered for broad compatibility across various heating and cooling systems. These controllers are adept at managing heat pump configurations (1H1C‚ 2H1C) and diverse HVAC systems (1H‚ 1C‚ 1H1C)‚ making them suitable for comprehensive climate control in both residential and commercial settings. Their robust design ensures efficient and reliable operation for different environmental needs.
Beyond core heating and cooling‚ the TH146 Series excels in integrating with a range of external devices to enhance functionality and user experience. Connectable devices include air recirculation fans for improved air distribution and humidifiers to maintain desired indoor humidity levels. For advanced energy management‚ a dual-register meter (dual energy) can be utilized. Moreover‚ the series supports remote control devices‚ particularly beneficial for engaging an unoccupied mode to optimize energy consumption when premises are vacant. Specific models like the TH146-N-U also accommodate dehumidifiers or air exchangers‚ offering an even more holistic approach to environmental climate management. These capabilities underscore the TH146 Series’ versatility in modern building automation.
TH150 Series for VAV Applications
The Aube TH150 Series electronic thermostat is specifically engineered for sophisticated low-voltage‚ pressure-dependent Variable Air Volume (VAV) applications. This specialized design ensures precise control over airflow and temperature within complex HVAC systems‚ optimizing comfort and energy efficiency in commercial and larger residential environments where VAV systems are commonly deployed. The series encompasses several distinct models‚ including the TH150-1A‚ TH150-1A2T‚ TH150-1F‚ and TH150-1F2T‚ each tailored to meet specific installation and control requirements.
These thermostats offer significant flexibility in managing VAV operations‚ capable of supporting up to three outputs. These outputs can be seamlessly integrated with various critical control devices. For instance‚ the TH150 Series connects effectively to actuators‚ which are essential for modulating VAV box dampers to regulate air supply. Furthermore‚ it supports thermal valves‚ including both Normally Open (N.O.) and Normally Closed configurations‚ facilitating precise temperature regulation by controlling hot or chilled water flow. This comprehensive connectivity allows the TH150 Series to provide granular control over the VAV system‚ ensuring optimal environmental conditions and maximizing operational efficiency in demanding applications.
Temperature Sensor AC146-410 Applications
The Aube Technologies Temperature Sensor AC146-410 is a versatile device primarily designed to enhance the functionality of Aube thermostats and controllers. Its core application involves accurately measuring temperature within specific environments‚ notably inside air ducts and air chambers. This capability is crucial for maintaining optimal climate control in HVAC systems‚ ensuring circulating air is at the desired temperature and contributing to energy efficiency by providing precise data for system adjustments.
Beyond its primary use in air ducts and chambers‚ the AC146-410 sensor is highly adaptable for various other temperature sensing applications. Its robust design and technical specifications‚ including a broad temperature range of -70 to 120°C (-94 to 248°F) and a resistive output signal‚ make it suitable for diverse industrial‚ commercial‚ and specialized residential settings. Examples include monitoring temperatures in refrigeration units‚ greenhouses‚ storage facilities‚ or even for process control where precise temperature feedback is essential. This flexibility extends its utility‚ allowing it to serve a wide array of temperature measurement needs.
